Quick Details

  • Condition: New
  • Brand Name: YTO
  • Model Number: WZ 30-25
  • Place of Origin: Henan, China (Mainland)
  • Type: Backhoe Loader, Backhoe Loader Spare Parts
  • Moving Type: Wheel Loader
  • Dimension(Long * Breadth * High): 7077*3424*2735
  • Rated Load: 7400kg
  • Warranty: 1 year or 1500 hours
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Backhoe bucket capacity: 0.3 m3
  • Rated loading bucket capacity: 1 m3
  • Rated Lifting Force: >25 KN
  • Engine's rated power/rated speed: 70/2200 KW
  • Max. grade ability: >30%
  • Max. traction power: 42KN
  • Min. turning radius: 4300mm
  • Engine: Weichai Deutz TD226B
  • Transmissions: CARRARO, Italy.

Packaging & Delivery

Packaging Details According to the contract: Backhoe Loader Spare Parts
Delivery Time 30 days after payment

Good Reputation 7ton Low Price On Sale Backhoe Loader Spare Parts





Product Description

Backhoe Loader Spare Parts WZ30-25 is a new multi-function engineering machine which gathers the loading and excavating in the integral whole machine. The engine is with low noise, low exhaust rate, environmented, and reliable. The acurated valve control take type brake system which ensure the in-time braking.so it is safer.









Main Features

1. Special mining loading mechanical chassis, the machine has compact structure, layout reasonable;
2. Configuration wide open fully enclosed ROPS bridge, the beautiful outlook, all-round human control system's leading design, so the control more reasonable and comfortable;
3. Engine using Weichai Deutz, environmental protection, power strong, greatly improve the fuel economy and work efficiency, and greatly reduce the customer use cost;
4. Adopt imported Italian professional mining loading transmission system, hydraulic system adopts domestic famous brand, guarantee the stability of the product quality, the machine performance reached the international advanced level;
5. Excellent excavation loading workability can bring customers value return;
6. With differential lock, wet braking import drive axle ensures the machine's traction performance and vehicle safety performance; Swing steering axle design, steering Angle and swing Angle, so that the vehicle has better through the sex; Crane brake and parking brake using free maintenance, self regulation, full control of wet type brake;
7. Two wheels, four-wheel drive, can meet the needs of customers;
8. The complete machine can according to customer needs is equipped with a variety of machines and tools.















Technical Parameter

Main technical parameter

Item

Unit

Backhoe Loader Spare Parts WZ30-25

Backhoe bucket capacity

m3

0.3

Rated loading bucket capacity

m3

1

Rated Lifting Force

KN

>25

Engine's rated power/rated speed

KW

70/2200

Total operating weight

Kg

7400

Backhoe turning angle

Left

º

90

Right

º

90

Backhoe parameter

Max. digging radius

mm

5481

Max. dump height

mm

3737

Radius at the max. dump height

mm

1084

Max. digging radius at ground level

mm

5437

Digging bucket's max. rotating angle

º

163.2

Max. digging depth

mm

4338

Max. digging force

KN

50+-10%

Loading parameter

Max. dump height

mm

2626

Dump reach at max. dump height

mm

726

(at dumping angle)

Bucket drawback angle

Transportation position

º

43.5

Ground position

º

36.5

Dump angle

º

43.5

Digging depth

mm

191

Max. breakout force

KN

>40

Max. grade ability

%

>30

Max. traction power

KN

42

Gear and travel speed

Forward/Backward gear I

km/h

5.8/7.0

Forward/Backward gear II

10.5/12.6

Forward/Backward gear III

20.1/24.3

Forward/Backward gear IV

40.2/48.6

Min. turning radius

mm

4300

Total length

mm

7077

Total height

mm

3424

Max. height (Cab)

mm

2735

Max. Width(outrigger)

mm

2250

Bucket width

mm

2328

(with attachment)

2313

(bucket max. width)



Configurations

Name

Item

Engine

Weichai Deutz TD226B

Transmissions

CARRARO, Italy.

Front/rear axle

Oil pump(working and reversing)

Chinese famous brand

Re-director

Chinese famous brand

Priority valve

Chinese famous brand

Hydraulic lock

Chinese famous brand

Hose and seal components

Chinese famous brand

Oil cylinder

Chinese famous brand

ROPS driving cab

KAT

Loading/digging valve

Chinese famous brand

Seat

Chinese famous brand

Special frame for loading/ digging

KAT

Brake pump

VIMOTER, Italy

Storage battery

VARTA

Hydraulic vibro-rammer(optional)



Hydraulic quartering hammer (optional)





Packaging & Shipping







Our Services

CUSTOMER SERVICE

We always insist “The customer is first, the client is best”. We do our effort to provide eligible products to all clients. Now we promise as follow:

1. According to the rule of law, the detailed rules of new system of guarantees, we provide guarantees for our products.

2. If there are quality objections in our Backhoe Loader Spare Parts because of designing, making, assembly and material, we'll repair, replacing in time.

3. We’ll give the Backhoe Loader Spare Parts to client as its 0 working hour. That’s can make sure the client use and maintain better.

4. We’ll reply on you in 4 hours as you meet the problem when you use Backhoe Loader Spare Parts according to the manual strictly. If we need support service at work site, we’ll settle the problem inside the province in 24 hours and outside province 72 hours. If the Backhoe Loader Spare Parts be aboard, the client should send the broken parts photo to us first, we’ll reply on you in 2 workdays.

5. We can help the customer to choose the Backhoe Loader Spare Parts’s model according to client’s demand. We’ll do our best to supply service in the course of sale. And we can give technical consultation, driver training and maintenance man training in our factory.

6. We promise support service for the Backhoe Loader Spare Parts till it reject. If the products was broken down over the period of warranty, we’ll support the service without free.

7. Our service department promise answer the phone call every day include holiday.

8. We’ll make record for every Backhoe Loader Spare Parts and tracing them in order to get the latest information of the Backhoe Loader Spare Parts. So we can give the better service for you.
