Quick Details

  • Condition: New
  • Type: Double Drum Roller, roller vibratory compactor
  • Static Linear Pressure: 289N/cm
  • Travel Speed: 0-11Km/h
  • Grade Ability: 40%
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: Luyang
  • Model Number: LTC210
  • Power(W): 75KW
  • Dimension(L*W*H): 4558X1840X2674mm
  • Weight: 10000kg
  • Certification: CE
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Diesel model: Cummins 4BT3.9
  • Engine power: 75KW

Packaging & Delivery

Packaging Details: Nude roller vibratory compactor
Delivery Detail: 30 days after receiving the down payment







Product Description







LTC210 Double Drum Hydraulic Vibratory Road Roller

LTC210 Hydraulic vibratory roller is manufactured according to international advanced technology and by use of imported components from abroad.The machine is a double drum tandem vibratory roller.It is primarily used for the compaction of road asphalt concrete,sand g ravel mixtures and RCC material,being a universal compaction equipment for highway,municipal road,park area and industry g round etc...



Main features:

1.Full hydraulic two wheel drive and Vibration.

2.Dual frequencies and dual Vibration amplitudes.

3.Hydrostatic center articulated steering, patented crab mechanism.

4.The driver's cabin is spacious and comfortable,equipped with rotary working seat,making the operation more     flexible and convenient.

5.The driver's cabin can be turned on one side as a whole, to facilitate maintenance.

6.Fork-type frame,good hold-down property.

Main technical Specifications:



Model

Unit

LTC210

Operating mass

kg

10000

Front axle load

kg

5000

Rear axle load

kg

5000

Static linear load

N/cm

238

From of frame



Fork-type

Crabwise movement distance

mm

±170

Water tank capacity

L

2X400

Fuel tank capacity

L

80

Hydraulic tank capacity

L

65

Vibration amplitude



High amplitude

mm

0.67

Low amplitude

mm

0.34

Vibration frequency



High amplitude

Hz

45

Low amplitude

Hz

50

Centrifugal force



High amplitude

KN

90x2

Low amplitude

KN

69x2

Travel speed

Km/h

0-11.1

Turning speed

mm

6000

Grade ability

%

40

Steering angle

°

±35

Drum diameter

mm

1150

Drum width

mm

1730

Drum rim thickness

mm

16

Transverse swing angle of the vibrating wheel

°

±8

Type of water spraying



Pressure

Ground Clearance

mm

324

Wheelbase

mm

3217

Overall length

mm

4558

Overall width

mm

1840

Overall height

mm

2674

Diesel model



Cummins 4BT3.9

Diesel power

KW

75

Diesel speed

r/min

2400
